| Model | KV (RPM/V) | ESC (A) | Max Power (W) | Max Current (A) | Weight (g) | Battery (LiPo Cells) | Internal Resistance (Ω) | Thrust / Pull (g) | Shaft Diameter | Motor Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| BD3536-5 | 1450 | 50A | 655 | 45.2 | 102 | 2–4S | 0.023 | 1380 | Ø5.0 mm | Ø35 × 36 |
| BD3536-6 | 1250 | 50A | 496 | 34.2 | 102 | 2–4S | 0.034 | 1270 | Ø5.0 mm | Ø35 × 36 |
| BD3536-8 | 1000 | 50A | 432 | 29.8 | 102 | 2–4S | 0.052 | 1160 | Ø5.0 mm | Ø35 × 36 |
| BD3536-9 | 910 | 50A | 370 | 25.5 | 102 | 2–4S | 0.036 | 1050 | Ø5.0 mm | Ø35 × 36 |
| Model | KV (RPM/V) | ESC (A) | Max Power (W) | Max Current (A) | Weight (g) | Battery (LiPo Cells) | Internal Resistance (Ω) | Thrust / Pull (g) | Shaft Diameter | Motor Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| BD3536-5 | 1450 | 50A | 655 | 45.2 | 102 | 2–4S | 0.023 | 1380 | Ø5.0 mm | Ø35 × 36 |
| BD3536-6 | 1250 | 50A | 496 | 34.2 | 102 | 2–4S | 0.034 | 1270 | Ø5.0 mm | Ø35 × 36 |
| BD3536-8 | 1000 | 50A | 432 | 29.8 | 102 | 2–4S | 0.052 | 1160 | Ø5.0 mm | Ø35 × 36 |
| BD3536-9 | 910 | 50A | 370 | 25.5 | 102 | 2–4S | 0.036 | 1050 | Ø5.0 mm | Ø35 × 36 |
