| Model | KV (RPM/KV) | ESC | Max Power (Watt) | Max Current (A) | Weight (g) | Battery (Lipo Cells) | Resistance (Ω) | Pull (g) | Shaft Diameter (mm) | Motor Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| BD2836-6 | 1500 | 40A | 368 | 25.4 | 70 | 2-4S | 0.041 | 1150 | 4.0 | 28x36 |
| BD2836-7 | 1120 | 40A | 336 | 23.2 | 70 | 2-4S | 0.070 | 1130 | 4.0 | 28x36 |
| BD2836-9 | 880 | 40A | 243 | 16.8 | 70 | 2-4S | 0.107 | 850 | 4.0 | 28x36 |
| BD2836-11 | 750 | 40A | 206 | 14.2 | 70 | 2-4S | 0.160 | 800 | 4.0 | 28x36 |
| Model | KV (RPM/KV) | ESC | Max Power (Watt) | Max Current (A) | Weight (g) | Battery (Lipo Cells) | Resistance (Ω) | Pull (g) | Shaft Diameter (mm) | Motor Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| BD2836-6 | 1500 | 40A | 368 | 25.4 | 70 | 2-4S | 0.041 | 1150 | 4.0 | 28x36 |
| BD2836-7 | 1120 | 40A | 336 | 23.2 | 70 | 2-4S | 0.070 | 1130 | 4.0 | 28x36 |
| BD2836-9 | 880 | 40A | 243 | 16.8 | 70 | 2-4S | 0.107 | 850 | 4.0 | 28x36 |
| BD2836-11 | 750 | 40A | 206 | 14.2 | 70 | 2-4S | 0.160 | 800 | 4.0 | 28x36 |
