| Model | KV (RPM/KV) | ESC | Max Power (Watt) | Max Current (A) | Weight (g) | Battery (Lipo Cells) | Resistance (Ω) | Pull (g) | Shaft Diameter (mm) | Motor Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| BD3530-8 | 1700 | 50A | 480 | 33.1 | 74 | 2-4S | 0.040 | 1240 | 5.0 | 35x30 |
| BD3530-10 | 1400 | 50A | 446 | 30.8 | 74 | 2-4S | 0.051 | 1180 | 5.0 | 35x30 |
| BD3530-14 | 1100 | 50A | 313 | 21.6 | 74 | 2-4S | 0.077 | 1100 | 5.0 | 35x30 |
| Model | KV (RPM/KV) | ESC | Max Power (Watt) | Max Current (A) | Weight (g) | Battery (Lipo Cells) | Resistance (Ω) | Pull (g) | Shaft Diameter (mm) | Motor Size (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| BD3530-8 | 1700 | 50A | 480 | 33.1 | 74 | 2-4S | 0.040 | 1240 | 5.0 | 35x30 |
| BD3530-10 | 1400 | 50A | 446 | 30.8 | 74 | 2-4S | 0.051 | 1180 | 5.0 | 35x30 |
| BD3530-14 | 1100 | 50A | 313 | 21.6 | 74 | 2-4S | 0.077 | 1100 | 5.0 | 35x30 |
